Arizona 8 Light Column with Illuminated Pole
Model#: UAR-211XX Ratings: IP65 IK07
Complementing the Arizona family of outdoor floodlight columns and wall mounted sconces, is the Arizona 8. The Arizona 8 is an 8.8" diameter column and incorporates precision optics that provides a type V distribution and type II, III and IV distribution housed within an ultra high impact clear acrylic lens. This modern aesthetic design can be used to light areas, such as campuses, parks, recreational areas and public spaces.This luminaire is provided with an integral driver housed within a waterproof electrical compartment secured inside the pole. The luminaire is pre-wired with power cord to the handhole to simplify installation. The Arizona is available with two different LED packages, namely COB which is available with a very wide type V distribution and the HP LED version for Type II, III and IV distributions.
The Arizona 8 is unique in the fact that the pole features a laser cut pattern with internal lighting for static white or color changing RGBW. Patterns can be customized to suit design.
Color temperatures include; 2700, 3000, 3500 and 4000 Kelvin for the Arizona top light. Reduced wattages can be provided to adhere to Title 24 requirements. For non standard fixture variations, as well as specific perforated reflector requirements and decoerative house side shields, please contact the factory. This product is provided complete with anchor bolts and a laser cut steel bolt template.
Spec Sheets and Downloads for Arizona 8 Light Column with Illuminated Pole
Specification Sheets
Arizona 2 Light Column Dia 8.8”
|
Model No. |
Watts
|
Lumens
|
Kelvin
|
Dimmable 1-10V
|
UAR-20973-21161 | 39/3x15 | 3657 lm | 27K,30K,35K,40K/RGBW Pole | • |
Photometric and Downloads
Product Information |
Arizona photometric IES |
Arizona CAD Files (2D / RFA / 3DS) |
IFC - BIM |
Dialux Files .uld |
